Xtreme ONU 1G Port

Xtreme ONU 1G Port

Xtreme ONU 1G Port is a cutting-edge optical network unit for high-speed connectivity. Designed for seamless data transmission, it offers 1Gbps performance. Ideal for both home and business setups, its reliable technology ensures stable connections. Elevate your broadband experience with Xtreme ONU's unmatched efficiency.

Specifications

·         Model Name: Xtreme ONU 1G Port

·         Port Type: Gigabit Ethernet

·         Speed: Up to 1 Gbps

·         Interface: Single SC/UPC connector

·         Optical Wavelength: Downstream - 1490nm, Upstream - 1310nm

·         Transmission Distance: Up to 20km

·         Power Supply: External 12V 0.5A adapter

·         Power Consumption: <5W

·         Operating Temperature: 0°C to 50°C

·         Storage Temperature: -10°C to 70°C

·         Supported Protocols: ITU-T G.984/G.988 standards

Key Features

·         Rate limitation and bandwidth control based on port, as well as support for IGMP Multicast for optimized broadband utilization.

·         VLAN capabilities to prevent broadcast storms and enable user segregation.

·         Compatibility with CTC interworking mode.

·         Automated features such as ONU discovery, link detection, and OLT remote software upgrades.

·         Enhanced diagnostic tools like DHCP option 60, power-off alarms for easier link problem identification, and remote loopback.

·         Dynamic Bandwidth Allocation (DBA) support.

·         Adheres to both IEEE802.1Q and IEEE802.1p VLAN protocols.

·         Provides flow statistics and storm control functionalities.

·         Fully compliant with the IEEE802.3ah standard.
